Code: 0912 002 2652
HARTING 09120022652 Han Q male insert with 5 contacts and crimp termination. Compact, high-density connector insert for reliable power and signal transmission in industrial applications. 2+ Earth Male Connector Axial Screw Size 3A (Current Rating 830V 40A)
Price on Application
2+ Earth Male Connector Axial Screw Size 3A (Current Rating 830V 40A)
Specifications
- Identification: Category Inserts
- Series : Han Q
- Identification : 2/0 High Voltage
- Termination method: Axial screw termination
- Gender: Male
- Size : 3 A
- Number of contacts: 2
- PE contact : Yes
- Pack contents: With heat shrink tube
- Conductor cross-section: 4 ... 10 mm²
- Rated current : 40 A
- Rated voltage : 830 V
- Rated impulse voltage: 6 kV
- Pollution degree : 3
- Insulation resistance : >1010 Ω
- Contact resistance: ≤ 1 mΩ
- Lightening torque:1.8 Nm
- Limiting temperature:-40+125 °C
- Mating cycles : ≥ 500
- Colour: RAL 7032 (pebble grey)
- Surface (contacts): Silver-plated
- China RoHS 50 REACH Annex XVII substances: Not contained
- REACH ANNEX XIV substances: Not contained
- REACH SVHC substances: Yes
- REACH SVHC substances: Lead
For further information, please send us an email at sales@futura.ie
