Code: 09 10 003 3005
HARTING 0910 003 3005 – Han 3A female insert with 3 poles and screw termination. Rated 10A / 230V, –40 °C to +125 °C. Compact, reliable solution for industrial connectors
Price on Application
3 position + Earth Male for locking lever Crimp type for 0.14 to 2.5mm wire
Specifications
- Manufacturer HARTING
- Series Han® 1A
- Packaging Bulk
- Part Status Obsolete
- Connector Type Insert
- Gender Male
- Number of Positions 3+Ground
- Size 1A
- Termination Style Crimp
- Voltage Rating 400V
- Current Rating (Amps) 10A
- Operating Temperature -30°C ~ 90°C
- Color Black
- Polyamide (PA), Nylon
- Material Flammability Rating
- UL94 V-0
For further information, please send us an email at sales@futura.ie
