Code: 0903 232 6825
HARTING 09032326825 DIN 41612 Type C 32‑pin female PCB connector with straight through‑hole solder termination, thermoplastic housing, gold‑plated contacts and wide operating temp for reliable industrial signal connections DIN41612 Type C 32 way Female Straight 4.5mm Solder Pins Rows A & C Class 2 Mating Cycles= 400
Price on Application
DIN41612 Type C 32 way Female Straight 4.5mm Solder Pins Rows A & C Class 2 Mating Cycles= 400
Specifications
- Manufacturer: HARTING
- Product Category: DIN 41612 Connectors
- Product: Receptacles
- Number of Positions: 32 Position
- Number of Rows: 3 Row
- Pitch: 2.54 mm
- Type: Type C
- Termination Style: Solder Pin
- Mounting Angle: Straight
- Current Rating: 2 A
- Contact Plating: Gold
- Contact Material: Copper Alloy
- Series: DIN-Signal C
- Packaging: Tray
- Product Type: DIN 41612 Connectors
- Rows Loaded: a + c
- Subcategory: Backplane Connectors
- Temperature range : -40°...+105°
- Tail Length: 4.5 mm
- Unit Weight: 12 g
