JT32C Oscillators TCXO HCMOS 10.0 - 54.0MHz 10.0 - 54.0MHz

Code: JT32C

Futura Electronics stockists of Jauch JT32C, TCXO HCMOS Oscillators. Complete range of Antennas & RF Connectors available online & in-store.






Price on Application

Jauch JT32C | Oscillators

JT32C  Oscillators TCXO HCMOS 10.0 - 54.0MHz  10.0 - 54.0MHz

Features:
  • -TCXO with HCMOS output, 3.2 x 2.5 mm
  • - excellent phase noise
  • - operating temperature range -40 °C ~ +85 °C
Specifications:
  • Frequency range 10.0 ~ 54.0 MHzAt +25°C ± 2.0 ppm
  • Aging first year ± 1.0 ppm
  • Supply voltage ± 0.2 ppm (at VDC ± 5 %)
  • Load change ± 0.2 ppm
  • Current consumption see table 1
  • Supply voltage VDC 2.5 V / 2.8 V / 3.3 V (± 5 %)
  • Temperature operating -30 °C ~ +75 °C / -40 °C ~ +85 °C
  • Storage -40 °C ~ +105 °C
  • Output rise & fall time 5.0 ns max.
  • Load max. 15 pF
  • Current max. 4.0 mA
  • Low-level max. 0.1 x VDC
  • High-level min. 0.9 x VDC
  • Output disable time max. 250 ns
  • Phase jitter 12 kHz ~ 20 MHz < 0.35 ps RMS max. / 0.2 ps RMS typ.
