JXS32 -WA SMD Seam Seal for wireless 3.2x2.5x0.7mm

Code: JXS32-WA

Tailor your wireless applications with our high-performance quartz crystals, offering 14 standard frequencies listed in the ESR for optimal compatibility. For a wider range of frequencies, consult the JXS22 datasheet. These crystals provide exceptional frequency tolerance of ±10 ppm at 25°C, with load capacitance options ranging from 8 pF to 12 pF, catering to diverse engineering requirements. Their low shunt capacitance of less than 3 pF, coupled with a robust operating temperature range of -40°C to +105°C, ensures reliable performance under various conditions. Designed for efficiency, they support a maximum drive level of 100 μW, with 10 μW recommended to prolong lifespan, and boast an impressive aging rate of less than ±1 ppm in the first year, making them ideal for critical wireless applications

Price on Application
Jauch  |  JXS32 - WA |   SMD Seam Seal for wireless 3.2x2.5x0.7

  • For wireless applications, 3.2 x 2.5 mm
  • Perfect reference crystal for wireless applications
  • For IoT using BlueTooth, ZigBee, NFC and more
  • High frequency stability and low ESR
  • Metal lid allows EMI shielding
  • Special frequencies for Wireless applications
  • 14 standard frequencies shown in ESR list (For other frequencies refer to general JXS22 datasheet)
  • Frequency tolerance at 25 °C ±10 ppm*
  • Load capacitance CL 8 pF / 9 pF / 10 pF / 12 pF*
  • Shunt capacitance CO < 3 pF
  • Storage temperature -40 °C ~ +105 °C
  • Drive level max. 100 μW (10 μW recommended)
  • Aging < ± 1 ppm first yea
