Code: TM2S8-C186
Panduit TM2S8-C186 Cable Tie Mounts – Durable & Versatile: Made from polypropylene, these metal-impregnated, chemical resistant mounts withstand temperatures from -40°F to 239°F (-40°C to 115°C). Ideal for secure wire management.
Price on Application
Panduit | TM2S8-C186 | Cable Tie Mount | 0.63mm x 50.3mm
Specification
- Product Type Cable Tie Mount
- Application Unique Cradle Design Provides Maximum Stability for the Cable Bundle and Low Profile Design Keeps Bundle Close to Mounting Surface
- Color Dark Blue
- Flammability Rating UL94-HB
- Environment Indoor
- Material Polypropylene
- Material Properties Metal-Impregnated
- Maximum Operating Temperature (°C) 115
- Maximum Operating Temperature (°F) 239
- Minimum Operating Temperature (°C) -40
- Minimum Operating Temperature (°F) -40
- Mount Method Screw-On
- Mounting Hole Thread Size #8 (M4)
- Overall Length (In.) 0.63
- Overall Length (mm) 16
- Overall Width (In.) 0.42
- Overall Width (mm) 50.3
- Overall Height (In.) 0.275
- Overall Height (mm) 7
- Resistance Properties Chemical-Resistant
- Standards Met RoHS Compliant
- For Use With Miniature, Intermediate, Standard Cross-Section Ties
